Ingersoll Rand 1000 Series Lubrication Pumps – A Flexible and Reliable Solution
The Ingersoll Rand 1000 Series Lubrication Pumps are designed to deliver exceptional performance, durability, and adaptability for a wide range of industrial applications. Built on the trusted internal gear principle, these pumps have been enhanced to meet the demands of OEM customers, offering advanced features that simplify installation and improve operational efficiency.
Precision Engineering and Customization
The side-ported design allows for the addition of SAE/DIN flanges, ensuring maximum flexibility in porting arrangements. This modular construction accommodates a variety of setups, making the pumps easy to integrate into new or existing systems. The innovative design focuses on delivering smooth, non-pulsating flow, self-priming capabilities, and reliable operation in demanding environments.
Why Choose the 1000 Series?
- Exceptional Durability: Constructed with high-grade materials for reliable, long-term performance.
- Customizable Design: Modular configurations adapt to specific system requirements.
- Easy Installation: Advanced features simplify the setup process.
- Proven Reliability: Trusted by OEMs and industries worldwide for consistent operation.
- Comprehensive Support: Ingersoll Rand provides expert service for every step of your project.
Conclusion
The Ingersoll Rand 1000 Series Lubrication Pumps combine precision engineering, robust materials, and adaptable features to deliver the perfect solution for lubrication, fluid transfer, and oil circulation needs. Whether in refrigeration compressors, gearboxes, or energy systems, these pumps offer superior performance and unmatched reliability.
Our manufacturing expertise and knowledge of applications enable us to not only provide you with an engineered solution, but we ensure your satisfaction with post-sales service. We pride ourselves on properly servicing you with specification, installation, operation and troubleshooting. The pump was originally designed to meet and exceed the exacting requirements of the refrigeration compressor market. The design has so many inherent features and benefits that our traditional customers are also seeing the advantages. The excellent performance of the 1000 series pumps are solving problems in many industries and varying, specific, high-pressure applications (261 psi). Contact us to review your application and determine if the highly performing, cost effective 1000 series pump is your engineered solution.
- Body: EN/GJL/250
- Rotor: Carbon Steel
- Idler Gear: Sintered metal or steel
- Self Priming
- Non-pulsating flow
- Mechanical seal fitted as standard (lipseal option only on direct mounted pumps)
- Choice of ball bearing or carbon bearings in body. Carbon Bushing Idler is standard
- Max speed: 1008-1010 up to 3600 rpm and for 1012-1024 up to 1750 rpm
- Max differential pressure 18 bar (261psi) For higher pressure consult the factory
- Max inlet pressure 45 bar (653psi) Dependent on type of mechanical seal fitted
- Max temperature 200ºC (392ºF)
- Modular design for ports and bushings
- Flange has an o-ring seal
