D-HP-High-pressure-Refrigerated-Dryers

Ingersoll Rand high pressure desiccant dryer with steel component provides intelligent features to realize maximum operation reliability. While one stainless steel vessel is drying the incoming air, the other vessel is regenerating the desiccant material, and this process cycles throughout the operating period to provide high quality clean air.

Utilizes superb quality high pressure switches for error-free operation
Automatic pressure loading and purging cycles, ensuring operation safety
High pressure desiccant materials used provides efficient drying and resistant to breakdown in order to guarantee a long lifespan
High efficiency silencers are used in conjunction with flow limiters to significantly lower job site noise.
PLC automatic controller for ease of end customer operation
Reliable robust pneumatic valves ensure no sudden pressure swings and maintains a stable outlet pressure
Combination filtration plus desiccant dryer design, small footprint with visually appealing compact design.

Air Cooled

	Capacity m³/hr Max Working Pressure bar	Capacity m³/hr Max Working Pressure bar	Capacity m³/hr Max Working Pressure bar	Capacity m³/hr Max Working Pressure bar	Power	Air Connections	Dimensions (mm)	Weight
Model	HP30A	HP35A	HP40A	HP55A	V/Ph/hz	(In/Out)	LxWxH	(kg)
D	32	36	40	44	220/1/50	NPT 1/2"	660×465×800	87
D	67	74	83	92	220/1/50	NPT 1/2"	660×465×800	92
D	116	128	143	158	220/1/50	NPT 1/2"	660×465×800	98
D	173	193	214	238	220/1/50	NPT 1/2"	720×520×800	105
D	232	257	285	316	220/1/50	NPT1"	720×520×800	125
D	289	321	356	395	220/1/50	NPT1"	720×520×800	135
D	347	385	428	475	220/1/50	NPT1°	760×560×820	145
D	405	449	449	554	220/1/50	NPT1°	760×560×820	160
D	463	514	570	633	380/3/50	NPT 1-1/4	760×560×820	175
D	521	578	641	712	380/3/50	NPT 1-1/4"	960×590×980	190
D	578	642	713	791	380/3/50	NPT 1-1/4"	960×590×980	205
D	636	706	784	870	380/3/50	NPT 1-1/4"	960×590×980	215
D	694	770	855	949	380/3/50	NPT 1-1/4"	1060×620×1180	225
D	810	899	998	1108	380/3/50	DN40	1060×620×1180	245
D	925	1027	1140	1265	380/3/50	DN40	1060×620×1181	265
D	1041	1156	1283	1424	380/3/50	DN40	1400×800×1300	290
D	1157	1284	1425	1582	380/3/50	DN50	1400×800×1300	330
D	1273	1412	1568	1740	380/3/50	DN50	1400×800×1300	350
D	1388	1541	1568	1740	380/3/50	DN50	1400×800×1300	350
D	1388	1541	1710	1898	380/3/50	DN50	1520×890×1400	380
D	1619	1798	1996	2215	380/3/50	DN50	1520×890×1400	420
D	1851	2054	2281	2531	380/3/50	DN65	1520×890×1400	460
D	2082	2311	2566	2848	380/3/50	DN65	1640×980×1520	510
D	2314	2568	2851	3164	380/3/50	DN65	1640×980×1520	580
D	2438	2706	3004	3334	380/3/50	DN65	1640×980×1520	630
D	2703	3000	3330		380/3/50	DN65	1640×980×1520	670

Air Cooled

	Capacity m³/hr Max Working Pressure bar	Capacity m³/hr Max Working Pressure bar	Power	Air Connections	Dimensions (mm)	Weight
Model	HP70A	HP80A	V/Ph/hz	(In/Out)	LxWxH	(kg)
D	51		220/1/50	NPT 1/2"	680×350×600	98
D	102		220/1/50	NPT 1/2"	680×350×600	98
D	153		220/1/50	NPT 1/2"	680×350×600	112
D	204		220/1/50	NPT 1/2"	680×350×600	112
D	255		220/1/50	NPT 1"	680×450×600	126
D	306		220/1/50	NPT 1"	680×450×600	126
D	357		220/1/50	NPT 1"	680×450×600	150
D	408		220/1/50	NPT 1"	680×450×600	150
D		56	220/1/50	NPT 1/2"	600×300×550	98
D		113	220/1/50	NPT 1/2"	600×300×550	98

Water Cooled

	Capacity m³/hr Max Working Pressure bar	Capacity m³/hr Max Working Pressure bar	Capacity m³/hr Max Working Pressure bar	Capacity m³/hr Max Working Pressure bar	Power	Air Connections	Dimensions (mm)	Weight
Model	HP30W	HP35W	HP40W	HP55W	V/Ph/hz	(In/Out)	LxWxH	(kg)
D				633	380/3/50	NPT 1-1/4"	680×450×680	175
D			641	712	380/3/50	NPT 1-1/4"	680×450×680	190
D		642	713	791	380/3/50	NPT 1-1/4"	770×540×800	205
D	636	706	784	870	380/3/50	NPT 1-1/4*	770×540×800	215
D	694	770	855	949	380/3/50	NPT 1-1/4*	770×540×800	225
D	810	899	998	1108	380/3/50	DN40	1080×700×1130	245
D	925	1027	1140	1265	380/3/50	DN40	1080×700×1130	265
D	1041	1156	1283	1424	380/3/50	DN40	1080×700×1130	290
D	1157	1284	1425	1582	380/3/50	DN50	1250×800×1300	330
D	1273	1412	1568	1740	380/3/50	DN50	1450×890×1420	350
D	1388	1541	1710	1898	380/3/50	DN50	1450×890×1420	380
D	1619	1798	1996	2215	380/3/50	DN50	1560×980×1500	420
D	1851	2054	2281	2531	380/3/50	DN65	1750×1005×1550	460
D	2082	2311	2566	2848	380/3/50	DN65	1910×1050×1600	510
D	2314	2568	2851	3164	380/3/50	DN65	2100×1080×1700	580
D	2438	2706	3004	3334	380/3/50	DN65	2100×1080×1700	630
D	2703	3000	3330		380/3/50	DN65	2100×1080×1700	570
