Oil-free Air Compressors P15-44kW

This product is capable of laser cutting, 20barg unit provides stable oil-free air source, high cutting efficiency and low energy consumption; it is capable of PET bottle blowing, 20-40barg box-type unit, plug-and-play, reduces on-site installation work, efficient oil-free blowing solution; it is capable of test and inspection, low-noise unit, flexible application scenarios, medium-pressure oil-free air, high-quality air source guarantee.


Focus on quality air

Air quality plays a decisive role in many situations. The presence of solid particles, condensate, oil and oil vapors in a compressed air system can lead to downtime, product damage and even product recalls and damage brand reputation and, worse, consumer interests and product credibility.



Reduced Life Cycle Costs

The initial cost of an oil-free system is higher, but lower lifecycle operating and maintenance costs optimize total cost of ownership while maintaining high air quality.



Increased Reliability

Reliable product and system design delivers quality air that protects sensitive downstream air-using equipment, reduces maintenance and extends equipment life.



Improved Productivity

Using certified oil-free, zero-rated compressors ensures zero air contamination, eliminating the risk of product damage and waste.



Improved serviceability

Designed with ease of maintenance in mind, it improves the ease of replacing consumables in the field.


Model

Nominal Power kW

Pressure bar

Flow(FAD) m3/min

Size LxWxHmm

Weight kg

P15S/20

15

20

1.3

1388x900x1416

700

P15S/30

15

30

1.1

1388x900x1416

700

P15S/40

15

40

1.0

1388x900x1416

700

P22S/20

22

20

2.0

1550x1050x1750

960

P22S/30

22

30

1.7

1550x1050x1750

960

P22S/40

22

40

1.5

1550x1050x1750

960

P15D/20

30

20

2.6

1850x1750x1700

1600

P15D/30

30

30

2.2

1850x1750x1700

1600

P15D/40

30

40

2.0

1850x1750x1700

1600

P22D/20

44

20

4.0

2000x1850x1800

1900

P22D/30

44

30

3.4

2000x1850x1800

1900

P22D/40

44

40

3.0

2000x1850x1800

1900

P15B/30

15

30

2.3-4.7

1388x900x1416

700

P22B/30

22

30

3.2-6.5

1550x1050x1710

960
