- Innovative Airend: Revolutionary efficiency in a compact footprint thanks to a patent-pending, semi-integrated airend that leverages a second gear on the drive shaft to optimise compression
- Decreased Energy Use: Premium efficiency motor with integrated variable speed drive (VSD) delivers significant energy savings to lower total cost of ownership
- Robust Design: Durable parts like solid hoses, pipe connections with Viton Victaulic couplings, and an innovative separator deliver reliability for the life of your compressor
- Enhanced Serviceability: Smart design elements like easy access to user-maintainable components and premium grade coolant reduce maintenance requirements and ensure increased uptime
- Remote Intelligent Control: Xe-Series controllers deliver increased functionality through an intuitive user interface, as well as remote access with any common, current web browser
- Intelligent Uptime: Integrated with Helix™ Connected Platform, a state-of-the-art system that gives you real-time insights and data to keep your compressor operating at peak performance and ensures uptime.
Ingersoll Rand works to keep you ahead of your competition with Next Generation RTe-Series air compressors that boost productivity, lower operating expenses and extend equipment life. And with a variable speed drive (VSD), the compressor automatically adjusts its compressed air output to achieve the highest efficiency for your operation, minimizing energy use at any load.
MODEL | Max pressure (barg) | Nominal power (kW) | Capacity (FAD)* (m3/min) | Dimensions (L x W x H) (mm) | Weight (kg) |
|---|---|---|---|---|---|
RTe110ne-A10 | 10 | 110 | 9.16-24.69 | 2907x2071x2193 | 4672 |
RTe132ne-A10 | 10 | 132 | 9.16-29.39 | 2907x2071x2193 | 4739 |
RSe160ne-A10 | 10 | 160 | 9.52 - 32.07 | 2907 x 2071 x 2193 | 4783 |
RSe200ne-A10 | 10 | 200 | 9.37 - 39.14 | 2907 x 2071 x 2193 | 5083 |
RSe250ne-A10 | 10 | 250 | 9.37 - 42.97 | 2907 x 2071 x 2193 | 5253 |
RSe290ne-A10 | 10 | 250 | 9.37 - 47.98 | 2907 x 2071 x 2193 | 5268 |
