ECO-Filter HF Main Filter Elements for Centrifugal Compressors

The ECO-Filter HF is a high-quality main filter element for centrifugal compressors that provides reduced energy costs and longer on-stream life. The innovative two-stage design provides up to a 40% lower clean pressure drop and up to an 89% higher dusting holding capacity as compared to competitive products.

Designed specifically for centrifugal air compressors, the ECO-Filter HF is an innovative inlet filter element that works to increase the life of your compressor while reducing your costs. The integrated two-stage element allows you to go longer between change outs to ease serviceability requirements.

  • Polyurethane gasket comes integrated with the filter frame and is highly pliable and seamless to ensure a leak-free seal
  • Micro-fiberglass filter media reduces clean air pressure drop to increase energy efficiency and has a 99.97% removal efficiency a 2.0 micron
  • Polystyrene frame is lightweight, corrosion resistant, and incinerable to enhance useful life

Part Number

Size

Weight

Clean Pressure Drop

Dust Holding Capacity

Temperature Rating

AAP1400009-00871

18" x 18"

20 lb

0.64" wg @ 1500 cfm; 0.36" wg @ 1000 cfm

483 g @ 1500 cfm; 774 g @ 1000 cfm

200 F

AAP0540009-00873

24" x 24"

28 lb

0.76" wg @ 3000 cfm; 0.42" wg @ 2000 cfm

900 g @ 3000 cfm; 1200 g @ 2000 cfm

200F
