- Efficiency: New efficient airend design increases efficiency by 11% & air capacity by 11%, and achieves long-lasting reliable operation.
- Reliability: It can remove lubricant in compressed air to below 3-5ppm, so as to protect downstream equipment, extend filter service life, increase productivity, and reduce maintenance cost for customers.
- Ease of Maintenance: RM7-22i fixed speed drive unit equipped with a standard self-tensioning belt system requires no manual maintenance, and thus reduces daily maintenance costs.
- Intelligence: Luminance series intelligent controllers achieve real-time monitoring of system parameters, whose standard IoT function enables you to learn air compressor status wherever you are, and pre-alarms to exempt you from losses due to unexpected sudden shutdown.
We utilize new state-of-the-art airend for development of the new RM series to deliver better performance for you. Through rotor profile optimization and many other improvements, the new airend can increase efficiency by 11% and reduce operating cost to a greater extent. Besides, new rotor profile achieves ideal air capacity, i.e. 11% more than the previous model. Smaller specific power means lower equipment investment cost and energy consumption, thus lowering your total cost.
Model | Rated Power kw | Nominal Pressure barg | Air Volume (FAD*) m3/min | Dimensions (LxWxH) mm | Weight kg |
iStandard unit performance | |||||
RMT15i_A RM15i_ATAS 350 | 15 | 7 | 2.5 | 984x1017x1065 1596x1246x1808 | 465 812 |
RMT15i_A RM15i_ATAS 350 | 15 | 8 | 2.4 | 984x1017x1065 1596x1246x1808 | 465 812 |
RMT15i_A RM15i_ATAS 350 | 15 | 10 | 2.07 | 984x1017x1065 1596x1246x1808 | 465 812 |
RMT15i_A RM15i_ATAS 350 | 15 | 12.5 | 1.7 | 984x1017x1065 1596x1246x1808 | 465 812 |
RM18i_A RM18i_ATAS 350 | 18.5 | 7 | 3.1 | 993x1020x1118 1596x1246x1808 | 509 856 |
RM18i_A RM18i_ATAS 350 | 18.5 | 8 | 3 | 993x1020x1118 1596x1246x1808 | 509 856 |
RM18i_A RM18i_ATAS 350 | 18.5 | 10 | 2.61 | 993x1020x1118 1596x1246x1808 | 509 856 |
RM18i_A RM18i_ATAS 350 | 18.5 | 12.5 | 2.15 | 993x1020x1118 1596x1246x1808 | 509 856 |
RM22i_A RM22i_ATAS 350 | 22 | 7 | 3.7 | 993x1020x1118 1596x1246x1808 | 524 671 |
RM22i_A RM22i_ATAS 350 | 22 | 8 | 3.6 | 993x1020x1118 1596x1246x1808 | 524 671 |
RM22i_A RM22i_ATAS 350 | 22 | 10 | 3.08 | 993x1020x1118 1596x1246x1808 | 524 671 |
RM22i_A RM22i_ATAS 350 | 22 | 12.5 | 2.72 | 993x1020x1118 1596x1246x1808 | 524 671 |
