- Portable Design: Heavy-duty ergonomic handle and semi-pneumatic tires for easy handling, ideal for DIYers or the professional
- User Friendly: A low 80 dBA noise level, an easily accessible side drain valve and an automatic start/stop pressure switch control provides a superior user experience
- Maximum Power: 100% continuous duty, along with 20 gallon receiver tank for tough applications
- Reliable Operation: All Season Select synthetic lubricant increases efficiency; with 2,000 hours of service between changeouts, it performs four times longer than petroleum-based lubricants
- Long-Life: Durable cast iron cylinder and frame, protective enclosed belt guard and manual overload motor protection provide excellent longevity
Designed for professionals and serious do-it-yourselfers, the versatile Garage Mate is ideal for the home, shop or job site. Delivering maximum air, the Garage Mate can power impact guns, ratchets, grinders, drills, nailers, paint sprayers, sanders and more. The Garage Mate features a cast-iron, oil-lubricated pump for solid, reliable performance. Belt-driven for quiet operation (75-80 dBA), all models are equipped with a pressure switch, pressure gauge, regulator, safety valve, manual drain and six foot power cord.
MODEL | P1.5IU - A9 | P1.5IU - A9 - H |
|---|---|---|
Flow at 90 psi (cfm) | 5.2 | 5 |
Max Pressure (psig) | 135 | 135 |
Nominal Power (hp) | 2 | 2 |
Flow at Max Pressure (cfm) | 4.6 | 4.6 |
Base Length (in) | 22 | 34 |
Base Width (in) | 23 | 16 |
Base Height (in) | 24 | 30 |
NPT Outlet (in) | 1/4 Quick Disconnect | 1/4 Quick Disconnect |
Voltage/Engine | 115/1/60 | 115/1/60 |
Tank (gal) | 20 Gallon Vertical | 20 Gallon Horizontal |
Weight (lbs) | 200 | 200 |
Reciprocating Air Compressor Single and Two Stage
Brochure, English
Garage Mate Compact Single-Stage Air Compressor
Brochure , English
Garage Mate Assembly Instructions
Assembly Instructions, English
Document Garage Mate Drawing
Technical Drawing, English
Reciprocating Air Compressor Quick Start Manual
Manual, English
Reciprocating Air Compressor Installation Manual
Manual, English
Reciprocating Air Compressor P1-IUA9 Twinstack
Manual, English
Reciprocating Air Compressor-Operators Manual SS3F2GM.pdf
Manual, English
