- Improved Efficiency: State-of-the-art, fully integrated airend delivers the efficiency and reliability you need
- Decreased Energy Use: Premium efficiency IP55 motor delivers significant energy savings, and the integrated variable speed drive (VSD) further decreases energy consumption
- Enhanced serviceability: Easy access to all user-maintainable components, auto-tensioning V-Belt, and Ingersoll Rand extended life, premium grade coolant ensures increased uptime
- Remote Intelligent Control: Xe-Series controllers deliver increased functionality through an intuitive user interface, as well as remote access with any common, current web browser
- Optional Total Air System (TAS): Clean, dry air in a single package that minimizes installation costs, reduces footprint and improves ISO air quality
- IES2 Advantage: Meets or exceeds IES2 standards for power drive efficiency
Ingersoll Rand works to keep you ahead of your competition with Next Generation R-Series air compressors that boost productivity, lower operating expenses and extend equipment life. And with a variable speed drive (VSD), the compressor automatically adjusts its compressed air output to achieve the highest efficiency for your operation, minimizing energy use at any load. Next Generation R-Series air compressors. The intelligence you need—to win.
MODEL | MAX PRESSURE (barg) | NOMINAL POWER (kW) | CAPACITY (FAD)* (m3/min) | Dimensions (L x W x H) (mm) | Weight (kg) |
RSe15n-A7.5 V3 | 7,5 | 15 | 2,6 | 787 x 698 x 1202 | 365 |
RSe15n-A10 V3 | 10 | 15 | 2,18 | 787 x 698 x 1202 | 365 |
RSe15n-A13 V3 | 13 | 15 | 1,67 | 787 x 698 x 1202 | 365 |
RSe18n-A7.5 V3 | 7,5 | 18,5 | 3,05 | 787 x 698 x 1202 | 381 |
RSe18n-A10 V3 | 10 | 18,5 | 2,62 | 787 x 698 x 1202 | 381 |
RSe18n-A13 V3 | 13 | 18,5 | 2,2 | 787 x 698 x 1202 | 381 |
RSe22n-A7.5 V3 | 7,5 | 22 | 3,54 | 787 x 698 x 1202 | 386 |
RSe22n-A10 V3 | 10 | 22 | 3,15 | 787 x 698 x 1202 | 386 |
RSe22n-A13 V3 | 13 | 22 | 2,66 | 787 x 698 x 1202 | 386 |
RSe15n-A7.5-TAS | 7,5 | 15 | 2,6 | 1963 x 813 x 1791 | 620 |
RSe15n-A10-TAS | 10 | 15 | 2,18 | 1963 x 813 x 1791 | 620 |
RSe18n-A7.5-TAS | 7,5 | 18,5 | 3,05 | 1963 x 813 x 1791 | 635 |
RSe18n-A10-TAS | 10 | 18,5 | 2,62 | 1963 x 813 x 1791 | 635 |
RSe22n-A7.5-TAS | 7,5 | 22 | 3,54 | 1963 x 813 x 1791 | 650 |
RSe22n-A10-TAS | 10 | 22 | 3,15 | 1963 x 813 x 1791 | 650 |
