- Intuitive Control: Ri comes standard with the Xe-Series controllers, delivering increased control and functionality through an intuitive user interface as well as remote access with any common, current web browser. Rn/ne comes with a new generation Luminance controller integrated with IoT for more powerful functions.
- Adaptive Monitoring: Progressive Adaptive Control (PAC™) system is fully integrated with the sensor and control system. It monitors key operating parameters and continuously adapts to prevent unexpected downtime.
- Advanced Cooling Systems: Unique design prevents hot air from flowing through critical electrical elements. Air pre-filter assembly greatly reduces cleaning time of coolers.
- Leak-free Design: V-Shield™ technology provides a totally integrated, leak-free design. Elastic Viton O-ring face seal connection is also used in flexible metal hoses with an internal fold design and unique external stainless steel braided wire mesh. This significantly improves reliability while reducing vibration.
- Optimised Drive Components: World-class single and two-stage airends (two-stage available starting at 90 kW), along with a TEFC induction or optional variable speed motor, minimise energy use.
Air compressor use accounts for a significant part of your energy costs. Our design team used advanced computer modeling techniques to create oil-flooded screw compressors that maximise efficiency and airflow, while operating reliably to improve your company's bottom line.
Model | Max. pressure | Nominal power | Air volume (FAD)* | Overall weight (air-cooled) | Overall weight (air-cooled) | |||||
barg | psig | kW | hp | m3/min | cfm | kg | lb | kg | lb | |
R90i | 7.5 | 110 | 90 | 125 | 16.71 | 590 | 2420 | 5335 | 2200 | 4850 |
R90i | 8.5 | 125 | 90 | 125 | 15.72 | 555 | 2420 | 5335 | 2200 | 4850 |
R90i | 8.5 | 145 | 90 | 125 | 14.02 | 495 | 2420 | 5335 | 2200 | 4850 |
R90i | 14 | 200 | 90 | 125 | 10.25 | 362 | 2420 | 5335 | 2200 | 4850 |
R110i | 7.5 | 110 | 110 | 150 | 20.76 | 733 | 2550 | 5620 | 2330 | 5140 |
R110i | 8.5 | 125 | 110 | 150 | 19.2 | 678 | 2550 | 5620 | 2330 | 5140 |
R110i | 8.5 | 145 | 110 | 150 | 17.5 | 618 | 2550 | 5620 | 2330 | 5140 |
R110i | 14 | 200 | 110 | 150 | 13.76 | 486 | 2550 | 5620 | 2330 | 5140 |
Model | Max. pressure | Nominal power | Air volume (FAD)* | Overall weight (air-cooled) | Overall weight (air-cooled) | |||||
barg | psig | kW | hp | m3/min | cfm | kg | lb | kg | lb | |
R9On | 7~10 | 100-145 | 90 | 125 | 8.47-17.95 | 299-634 | 2060 | 4540 | 1850 | 4080 |
R11On | 7~10 | 100-145 | 110 | 150 | 8.47-21.66 | 299-765 | 2060 | 4540 | 1850 | 4080 |
R132n | 7~10 | 100-145 | 132 | 175 | 8.47-24.44 | 299-863 | 2363 | 5210 | 2354 | 5190 |
R160n | 7~10 | 100-145 | 160 | 215 | 8.47-28.88 | 299-1020 | 2363 | 5210 | 2354 | 5190 |
R9One | 7~10 | 100-145 | 90 | 125 | 8.86-18.72 | 313-661 | 2495 | 5500 | 2472 | 5450 |
R11One | 7~10 | 100-145 | 110 | 150 | 8.86-22.96 | 313-811 | 2495 | 5500 | 2472 | 5450 |
R132ne | 7~10 | 100-145 | 132 | 175 | 8.86-27.24 | 313-962 | 2495 | 5500 | 2472 | 5450 |
R16One | 7~10 | 100-145 | 160 | 215 | 8.86-32.05 | 313-1132 | 2495 | 5500 | 2472 | 5450 |
